01-14-2024 10:23 PM - edited 01-15-2024 01:19 PM
I made a battery grip for the R5C using the canon BP-A 30 batteries. Now I have 8k 60p no limitations, and battery anxiety is also nonexistent now 😂. Also getting about 2 1/2 hours of use. Thought I would share this because if I can make this you can too. Also canon can make this too. Canon or whoever please steal this idea make it better.
made of; NEWEER battery grip, 12v to 9v converter, canon DR-E6C converter, AND Dolgen BPA engineering battery plate.
I had to create a metal piece to connect the battery grip to the battery plate, and I had to solder it in two different places. I also use a tripod plate/shoe to add more pressure to keep it in place.
I have use this on my professional shoots to great success. I bought a second camera R5C and made a second battery grip for my two camera shoots.
The only other thing that’s on my wish list for this camera is shooting in a 8K 60P in the HEVC format
01-14-2024 11:04 PM
This is fantastic! Quite an elegant solution using the DR-E6C inside of the battery grip – when I saw the first picture, I was expecting that there was a USB-C cable hanging off the side out-of-site, but this looks clean!
Do my eyes deceive me, or is the battery charge level being displayed on the camera's display?
P.S. Canon / any 3rd party, please do make a version of this where the battery can be fully recessed inside of the grip – I think such a product would find a lot of happy customers!
01-15-2024 01:16 PM
Greetings,
Remarkable and quite ingenious.
~Rick
Bay Area - CA
~R5 C (1.0.7.1) ~RF Trinity, ~RF 100 Macro, ~RF 100~400, ~RF 100~500, ~RF 200-800 +RF 1.4x TC, BG-R10, 430EX III-RT ~DxO PhotoLab Elite ~DaVinci Resolve Studio ~ImageClass MF644Cdw/MF656Cdw ~Pixel 8 ~CarePaks Are Worth It
04-25-2024 10:30 AM
Please submit your design to SmallRig Co-Design:
https://www.smallrig.com/co-design
05-23-2024 10:59 AM
wow! ...can I buy one from you...?
09-18-2024 07:27 PM
Hi, what is the spec for the output for the R5C-specific dummy dc connector? I am trying to see if I can solder a Dtap with a booster to get the correct voltage.
09-18-2024 09:18 PM
9 volt is what I set it too.
